ITF 14

ITF 14 barcode generator

Use Labeljoy software to generate ITF 14 barcodes. ITF 14 is used mainly on freight shipments and packages containing coded with EAN 13 system. A digit is placed in front of the EAN 13 code to display the version of the package.

It always encode 14 digits:

  • The first digit is the variant logistics, also called “Packaging indicator”.
  • The other 12 digits are the product number. Generally EAN 13 without the check digit.
  • The last digit is the check digit.

The thick black border around the symbol is called the Bearer Bar. Labeljoy ITF 14 generator automatically creates Bearer Bar. The purpose of a Bearer Bar is to equalize the pressure exerted by the printing plate over the entire surface of the symbol.

ITF-14 symbol

ITF-14 symbol

How to generate ITF 14 barcode

Labeljoy ITF-14 generator requires you to enter 13 or 14 digits to generate the ITF 14 barcode, depending on the settings in the Checksum combo box.
Enter the 13 digits in the text box if the Checksum options is set to Yes (the 14th digit will be automatically added), otherwise enter 14 digits.
The need of a checksum in position 14 may vary depending on the applications in use and the targeted barcode scanner settings.

Bearer bars in ITF 14

The Frame combo box enables you to specify how the Bearer bars should be printed.

ITF-14 horizontal bars

ITF-14 with horizontal only bearer bars

ITF-14 barcode hidden bars

ITF-14 with hidden bearer bars

Text concatenation:
When an ITF-14 barcode element is generated by concatenating fields or counters, the following rules apply:

  • If the Checksum option is set to Yes, only the first 13 digits found will be considered, otherwise only the first 14 digits will be considered.

When a value not complying with the above rule is found, the barcode is not displayed.

The human readable text can also be shown above the symbol or hidden according to the setting specified in the Text combo box.

ITF-14 with text above

ITF-14 with text above the symbol

ITF-14 hidden text

ITF-14 with hidden text
